The BDLYTE Electrolyte Analyzer delivers fast, accurate electrolyte measurements using advanced Ion Selective Electrode (ISE) technology. Built for reliability and simplicity, it provides laboratories with precise analysis of key ions like sodium (Na⁺), potassium (K⁺), calcium (Ca²⁺), chloride (Cl⁻), and pH — all with minimal reagent consumption and easy maintenance.

Key Features

• ISE Technology: Utilizes ion-selective electrodes for highly accurate and stable results.
• Fast Analysis: Produces reliable readings within 60 seconds with a throughput of up to 60 samples per hour.
• Low Reagent Consumption: Optimized internal system reduces waste and operating costs.
• Easy Operation: Simple 3-key control and automatic calibration make operation user-friendly.
• Built-In Printer: Integrated 58mm thermal printer delivers instant test reports.
• Self-Monitoring System: Features automatic diagnostics and tracking to prevent electrode drift and ensure long-term accuracy.
• Durable Design: CNC metal anodized chamber and transparent electrode housing for easy maintenance and long service life.

Specifications

• Measuring Method: Ion Selective Electrode (ISE)
• Parameters: K⁺, Na⁺, Cl⁻, Ca²⁺, pH
• Sample Type: Whole blood, serum, plasma, QC, and dilute urine
• Sample Volume: 100 µL
• Analysis Time: ≤ 60 seconds
• Calibration: Fully automatic with A/B calibration and manual option
• Display: Backlit LCD screen
• Printer: Built-in 58mm thermal printer
• Data Interface: RS-232C serial port
• Accuracy (CV): ≤1% for K⁺, Na⁺, Cl⁻, pH; ≤2% for Ca²⁺
• Power Supply: 220V ±22V, 50Hz ±1Hz
• Dimensions: 33.5 × 28.0 × 29.5 cm | Weight: ~6 kg
• Operating Range: 5°C–40°C; ≤85% RH (non-condensing)
